OSH Park
Shared projects
kkkkkkkkk
by
interconnect.
2
layer board of
0.79x0.79
inches
(20.02x20.02
mm).
Shared on
December 5th, 2015 14:32.
AIC
by
interconnect.
2
layer board of
2.07x0.87
inches
(52.48x22.00
mm).
Shared on
December 5th, 2015 14:32.
interconnect
by
interconnect.
2
layer board of
0.79x0.79
inches
(20.02x20.02
mm).
Shared on
December 5th, 2015 14:32.
OpenSprinkler Pi 1.42
by
nmigl.
2
layer board of
4.10x3.29
inches
(104.01x83.52
mm).
Shared on
December 4th, 2015 09:24.
Open-source Sprinkler Valve Controller
BNO055LiPoBoard.v02
by
PeskyProducts.
4
layer board of
0.95x0.33
inches
(24.03x8.28
mm).
Shared on
December 4th, 2015 08:25.
BNO055 Motion sensor, MAX1555 LiPo battery charger, TLV70728 LDO voltage regulator, W25Q80BLUXIG 8 Mbit SPI Flash Memory, and a M41T62LCC RTC on a very small board.
