TV B GONE
by
Doctore.
2
layer board of
0.79x0.79
inches
(20.02x20.02
mm).
Shared on
June 23rd, 2015 22:45.
v1
Apple 1 Replica
by
Muxelmann.
2
layer board of
3.90x2.44
inches
(99.01x62.00
mm).
Shared on
June 23rd, 2015 20:59.
Simple Apple 1 replica with breakout shield
Edison Audio Block V1.0
by
Serge.
2
layer board of
1.20x2.80
inches
(30.58x71.22
mm).
Shared on
June 23rd, 2015 18:13.
Audio block for Intel Edison board based on WM8731 codec
Sensor Board
by
LukasCepec.
2
layer board of
0.96x2.05
inches
(24.33x52.10
mm).
Shared on
June 23rd, 2015 17:56.
senzor board for FPGA board. Are used three kind of sensors. HIH6000, DS18B20, MS5607-02BA03. It is board for school project
SPI to parallel converter.
by
Liv-Tech.
2
layer board of
1.11x0.80
inches
(28.27x20.32
mm).
Shared on
June 23rd, 2015 17:27.
SPI to Parallel converter using 74HC595 in dip form factor. An easy way to add outputs to arduino or any microcontroller that has an SPI port. Video of it in action
