BlueSaab v3.3
by
Edison517.
2
layer board of
2.36x2.44
inches
(59.97x61.95
mm).
Shared on
February 11th, 2016 19:13.
Added additional bottom silk screen labels to RN52. MINOR tweak to BT1 and BT2 vias. Added Hardware Rev resistor R13 with R14 (resistor divider network) for possible future use. Added R15 & C10 for outputting pwm power signal to PWREN pin on RN52. Added SMD jumper to short GPIO7 to ground to force 9600 baud instead of 115200.
TEST: copy of CHIP_pwm_shield
by
fustini.
2
layer board of
1.63x1.99
inches
(41.43x50.42
mm).
Shared on
February 11th, 2016 18:07.
TEST: I uploaded CHIP_pwm_shield by KoljaWindeler. simple PWM, mosfet shield to drive led strips with the C.H.I.P. GitHub: https://github.com/KoljaWindeler/CHIP_pwm_shield Forum: https://bbs.nextthing.co/t/salsa-dip-for-c-h-i-p-i2c-arduino-ws2812-pwm-motor/1597/70
IGBT Bridge V1
by
Extreme-Electronics.
2
layer board of
2.39x2.38
inches
(60.66x60.33
mm).
Shared on
February 11th, 2016 17:21.
IGBT Bridge V1 Cockup - Two transistors have heat sink mount in the middle of the board. more details at extelec.uk/brg
pad box 1
by
marsabeta.
2
layer board of
3.23x1.73
inches
(81.99x43.94
mm).
Shared on
February 11th, 2016 15:58.
