Cyclone V Bucky Buddy
by
metacollin.
2
layer board of
1.36x0.77
inches
(34.65x19.63
mm).
Shared on
September 18th, 2015 01:23.
A 4 channel buck converter with I2C digital control for powering FPGAs. This one is specific to the Cyclone V but can be adapted easily. All files released under the MIT License and available on Github
Mirco FM Spy bug
by
JaredNew.
2
layer board of
0.89x0.42
inches
(22.50x10.62
mm).
Shared on
September 17th, 2015 19:43.
FM Spy Transmitter
test
by
rai.
2
layer board of
0.47x0.62
inches
(12.04x15.77
mm).
Shared on
September 17th, 2015 15:57.
test
RC-Schalter
by
Viper-Gtr.
2
layer board of
0.47x0.38
inches
(11.84x9.75
mm).
Shared on
September 17th, 2015 13:45.
RC-Schalter mit ATtiny85. Dieser übernimmt den Servoeingang und gibt ihn: 1. als Schaltkanal aus 2. als PWM von 0 - 100% aus
EM7180+LSM9DS1+LPS25H.v01a
by
PeskyProducts.
4
layer board of
0.71x0.51
inches
(17.91x12.83
mm).
Shared on
September 17th, 2015 06:36.
Breakout board for LSM9DS1 9 DoF motion sensor plus LPS25H altimeter with the EM7180 SENtral sensor fusion hub to test inclusion of pressure data in the 9 DoF sensor fusion result. Replaced INT_M with DRDY_M.
