Open Panzer Tamiya IR LED Adapter
by
OpenPanzer.
2
layer board of
0.28x0.75
inches
(7.11x19.02
mm).
Shared on
March 7th, 2016 01:03.
Small adapter board for use with the Open Panzer Tank Control Board (TCB). On one end of the board you solder the leads from a 2-pin JST-XH pigtail, on the other end a right-angle Molex Micro-Latch connector. This allows Tamiya IR LEDs (Item #7255030) to be completely plug-and-play with the TCB.
See the Accessories page of the Open Panzer TCB wiki for more information.
Resources:
.
simulator
by
edc_atl.
2
layer board of
2.49x1.43
inches
(63.17x36.20
mm).
Shared on
March 6th, 2016 23:48.
engine simulator
iPod Connector
by
jsantosrico.
2
layer board of
0.56x1.05
inches
(14.20x26.67
mm).
Shared on
March 6th, 2016 20:00.
Philips DS1100 iPod Connector
Radio Buttons Panel
by
jsantosrico.
2
layer board of
3.43x0.87
inches
(87.02x22.02
mm).
Shared on
March 6th, 2016 20:00.
Panel used to hold two dials for my radio restoring project. One of them is used as soft latch power button and the other one as a rotary encoder to change the volume
RFD102A
by
RFD-8-pad-breakout.
2
layer board of
0.40x0.40
inches
(10.16x10.16
mm).
Shared on
March 6th, 2016 16:39.
RFD102A Breakout board. Well, other RFD chips work with it also (RFD88A, RFD103A).
