FPV Video PCB / PDB
by
Airic-Lenz.
2
layer board of
1.19x0.91
inches
(30.12x23.11
mm).
Shared on
August 8th, 2015 15:29.
A little PCB designed to provide a neat FPV PDB. The PDB includes power filtering for a clean supply to the video TX as well as to the camera.
BOM:
- L101 - 100uH 0.62A (WE-PD SMD 7332)
- C101 - 0.1uF (SMD 0603)
- C102, C103 - min 100uF, min 20V (electrolytic cap SMD 8x10mm)
- U101 - 1117 5V regulator (SOT-223)
Visual Alarm Rev3
by
nm3210.
2
layer board of
2.56x1.26
inches
(65.02x31.95
mm).
Shared on
August 8th, 2015 13:39.
RGB LED Controller w/ RTC Input
Hermes Lite Superband-B 5W Power Amplifier v1.3
by
AC9HY.
2
layer board of
2.70x2.37
inches
(68.48x60.12
mm).
Shared on
August 8th, 2015 11:28.
Uses a BPF filter design for any pair of the following - 160, 80/75, 60/40, 30/20, 17/15 or 12/10.
esp13pin
by
lamloei.com.
2
layer board of
1.00x1.00
inches
(25.43x25.43
mm).
Shared on
August 8th, 2015 09:18.
esp13pin
Hedley Magneto-Resistive Sensor - Rev C
by
AndrewIC.
2
layer board of
1.97x1.04
inches
(49.96x26.47
mm).
Shared on
August 7th, 2015 19:39.
Stackable with the one-bell simulator interface board.
