SAV 3D LCD




Pricerange: $ 00.00

http://blog.electrofunltd.com/2014/02/sav-3d-lcd.html
http://reprap.org/wiki/SAV_3D_LCD

Specifications

Parameter Description
LCD type Hitachi HD44780 alphanumeric, 20x4, Blue background white text
LCD interface 2 wire shift register
Control Quadrature rotary encoder with push button, 24 PPR
Push button 2 (predefined for KILL and HOME)
Connection 3M boxed connector to LCD and expansion module
14 wire ribbon cable
Expansion module 1 IO
5V regulated output 62dB ripple rejection - Typ
